It will be the first SF6-free 420 kV gas-insulated substation circuit-breaker in the world
The 420 kV gas-insulated substation. (Credit: General Electric)
GE Renewable Energy’s Grid Solutions business has secured €2.2m European Union (EU) funding to support the development of the g³ circuit-breaker.
The funding for the project has been provided through the European Commission’s LIFE climate action programme.
The new circuit-breaker will be developed using GE’s industry’s Green Gas for Grid or g³ technology.
The company claims that it will be the first SF6-free 420 kV gas-insulated substation circuit-breaker in the world. A circuit-breaker is protective equipment which is employed to cut power during an issue with the grid.
The gas mass of g³ high-voltage products has more than a 99% reduced carbon dioxide equivalent compared to SF6.
GE’s g³ circuit-breaker is expected to completed in 2022
The sulphur hexafluoride (SF6)-free, 420 kiloVolt (kV) 63 kilo Amps (kA) gas-insulated substation (GIS) circuit-breaker is expected to completed in 2022.
Grid Solutions’ materials and eco design team leader and project leader for the EU-funded g³ project Yannick Kieffel said: “Because 420 kV is the highest voltage level used in most European countries, a proven g³–insulated 420 kV circuit-breaker will demonstrate that g³ technology can be applied to other high-voltage levels, as well as all other gas-insulated substation components, such as disconnectors, earthing switches, voltage transformers.”
For the g³ project, GE’s Grid Solutions teams will work with quite a few European partners.
The scientific database of the project will be developed by the Czech Republic’s Brno University and Germany-based Leibniz Institute for Plasma Science and Technology.
On the other hand, CEA will be involved in the circuit-breaker development while Transmission System Operators (TSOs) will help test and implement the final product.
UK-based National Grid, France’s RTE and TenneT in Germany are part of the 18 utilities that have installed GE’s g³ equipment at 23 sites.
GE claims that these projects have helped in reducing over 409,000 tonnes of carbon dioxide equivalent on the grid.
The company stated: “Due to its strong insulating and arc-quenching properties, SF6 is widely used in substation equipment with the transmission industry accounting for approximately 80% of the world’s usage.
“Identified as the world’s most potent greenhouse gas by the 1997 Kyoto Protocol, SF6 is estimated to contribute 23,500 times more emissions than CO₂ if leaked and can remain in the atmosphere for up to 3,200 years.”
